Description

Temperature sensor suitable for measurement of liquids, semi-liquid masses or loose materials. Temperature measurement can be carried out in a temporary or permanent way. This sensor has sheath with threaded connector.

Files

Contact with a consultant

Telephone: +48 (18) 330 10 06

Fax: +48 (18) 330 10 04

E-mail: [email protected]

Do you have a question?
General Connection heads Compatible devices Additional accessories Contact form

Temperatura range

  • -50÷150ºC      RTD



Specification

  • sensing element: Pt100/Pt500/Pt1000
  • process connection with G1/2, G3/8 other
  • connection head type MA, IP54, -40÷100ºC
  • sheath material: acid-resistant steel 1.4541



Mounting



Connection heads

Connection head type MA in standard.

MA


For details see "connection heads

Cooperating devices

Temperature sensors can cooperate with the devices registering parameters of the controlled process.

Temperature Indicators Controllers Recorders


For details see: indicators,controllers, “data loggers”

Additional accessories

Some applications require the use of additional accessories suitable for their individual requirements.

Transmitters Welding adapters Mounting fittings

Plugs and Sockets Compensations Cable Protection Tube


For details see: transmitters, "welding adapters", "mounting fittings", "plug and sockets", "compensation cables", "protection tubes"
