Description

Temperature sensor suitable for pipelines, pressure tanks and other devices used in food and pharmaceutical industry. This stainless steel sensor has National Institute of Hygiene (PZH) attestation.

Files

Contact with a consultant

Telephone: +48 (18) 330 10 06

Fax: +48 (18) 330 10 04

E-mail: [email protected]

Do you have a question?
General Connection heads Compatible devices Video Additional accessories Contact form

Temperatura range

  • -200÷400ºC        RTD
  • -40÷400ºC          TC



Specification

  • sensing element: Pt100/Pt500/Pt1000 resistor or J, K, N, T thermocouple
  • process connection with M10x1 or M20x1,5 thread
  • connection head type MBEG – material: stainless steel 1.4541, IP65 -40÷100°C
  • sheath material: acid-resistant steel 1.4541
  • national Institute of Hygiene (PZH) attestation



Mounting



Connection heads

Connection head type MBEG in standard.
Possibility to mount the connection head of a different type.

MBEG


For details see: "connection heads

Cooperating devices

Temperature sensors can cooperate with the devices registering parameters of the controlled process.

Temperature Indicators Controllers Recorders


For details see: indicators,controllers, “data loggers”

Additional accessories

Some applications require the use of additional accessories suitable for their individual requirements.

Transmitters


For details see: transmitters
