Large Limatherm Sensor temperature controller. It has a universal input suitable for most common thermocouple sensor as well as Pt100. Low or standard 230V power supply can be selected. Up to 3 outputs programmed as alarm or control outputs, 3 universal outputs including SSR 14V for control of three-phase semiconductor relays  or 4÷20mA (control or retransmission). Two displays: upper red colour presents temperature of process; lower green colour presents set temperature. Black enclosure, anti-reflection coating and clear indication. Degree of protection of front panel IP65. There is a possibility to block the access to specified parameters via software.


Contact with a consultant

Telephone: 18 330 10 22

Fax: 18 330 10 04


Do you have a question?
General Compatible devices Additional accessories Contact form


  • programmable temperature controller
  • 4 digit dual LED display
  • PID control; ON/OFF control
  • auto-tuning
  • sensor offset
  • front panel: IP65



  • universal input: TCRTD
  • output: 2xrelay
  • third-purpose programmable output 4-20mA, SSR 14V
  • power supply: 230V AC, 24V DC / AC ±10%
  • dimensions: 96 × 96 × 92; otwór; 92,5 × 92,5 mm
